Vessel Specifications & Production History
Production Years: 1993–1995 (re-badged as the Carver 445 Aft Cabin from 1996–1999).
Production Volume: Estimated in the low hundreds across its three-year run; served as Carver’s flagship model upon introduction in 1993.
Production Facility: Pulaski, Wisconsin, USA.
Design Team: Carver In-House Naval Architecture & Engineering Team.
Model Evolution: Introduced in 1993. Replaced in 1996 by the Carver 445 Aft Cabin (identical hull/interior with an integrated molded swim platform replacing the bolt-on platform), which later led into the Carver 444 Cockpit Motor Yacht line.
Layout Configurations:
- Two-stateroom, two-head layout with master walkaround queen aft and forward guest berth.
- Options included:
- salon lower helm station
- convertible salon U-shaped dinette (sleeping up to 8 adults)
- galley dinette versus lounge setup.
Draft: draft is 4’3″ (1.30 m). Modified-V hull with solid fiberglass bottom and running keel for tracking stability
Bridge Clearance / Height: 18’9″ (5.72 m) to top of radar arch.
Engine Options:
- Cummins 6CTA 8.3L Turbo Diesels (420 HP – 450 HP)
- Cummins 6BTA 5.9L Turbo Diesels (300 HP – 330 HP
- Caterpillar 3208TA Diesels (375 HP)
- Crusader 454 XL / 502 XLi Gasoline V8s (350 HP – 420 HP)
Drive Systems: Inboard Direct Drive (1.75″ to 2″ stainless shafts with 4-blade bronze propellers).
Major Factory Options: Kohler or Onan generator (8.0–11.0 kW), triple-zone reverse-cycle AC/heat, foredeck davit/crane, aft deck wing doors, and full flybridge/aft enclosure.
Market Value Drivers & Common Issues
Aluminum Fuel Tank Corrosion: Dual 238-gallon aluminum saddle tanks located along hull sides can suffer beneath-the-surface pitting from trapped moisture. Replacement is labor-intensive due to narrow access pathways through the aft cabin or engine space.
Galley Appliance Dimensions: Original full-size refrigerators are difficult to extract through companionway entry doors without removing trim or door frames.
Window Frame & Deck Seals: Wraparound salon windows and radar arch joint seals require regular recaulking to prevent water ingress onto interior cabinetry.
Gas vs. Diesel Engine Depreciation: Gasoline-powered units (Crusader 454/502) trade at a substantial market discount compared to Cummins or Cat diesel models.
Geographic Dispersion: Freshwater Great Lakes and inland river boats command premium pricing due to lower corrosion, limited UV wear, and seasonal usage compared to coastal saltwater units.
Competitive Model Comparison
| Specification | Carver 440 Aft Cabin | Sea Ray 440 Aft Cabin | Silverton 442 Cockpit MY | Bayliner 4387 Motor Yacht |
| Years Produced | 1993–1995 | 1989–1991 | 1998–2001 | 1990–1996 |
| LOA | 47′ 8″ | 45′ 11″ | 45′ 11″ | 43′ 0″ |
| Beam | 15′ 0″ | 13′ 11″ | 14′ 3″ | 14′ 3″ |
| Draft | 4′ 3″ | 3′ 6″ | 3′ 6″ | 3′ 6″ |
| Dry Weight | 32,000 lbs | 23,000 lbs | 28,500 lbs | 20,000 lbs |
| Fuel Capacity | 476 gal | 400 gal | 375 gal | 300 gal |
| Water Capacity | 165 gal | 140 gal | 120 gal | 105 gal |
| Hull Design | Modified-V (14° deadrise) | Modified-V | Modified-V | Modified-V |
| Primary Engines | Cummins 6CTA / Crusader 502 | Caterpillar 3208TA | Cummins 6BTA / Crusader 454 | MerCruiser 7.4L / Hino Diesel |
